HYDROLUX

Waterdicht armatuur IP69K

EIGENSCHAPPEN

TOEPASSINGEN

HYDROLUX PC – IK10

ARTIKEL	CCT	LUMEN	WATT	DIM	NOOD	SENSOR	LENGTE mm
HDPC06204	4000	3264	20	-	-	-	552
HDPC06204DA	4000	3264	20	DALI-2	-	-	552
HDPC06204MW	4000	3264	20	-	-	MW	552
HDPC06204UGR	4000	3264	20	-	-	-	552
HDPC06204UGRDA	4000	3264	20	DALI-2	-	-	552
HDPC06204UGRMW	4000	3264	20	-	-	MW	552
HDPC12404	4000	6528	40	-	-	-	1152
HDPC12404DA	4000	6528	40	DALI-2	-	-	1152
HDPC12404DAEM	4000	6528	40	DALI-2	EM3H	-	1152
HDPC12404EM	4000	6528	40	-	EM3H	-	1152
HDPC12404MWEM	4000	6528	40	-	EM3H	MW	1152
HDPC12404MW	4000	6528	40	-	-	MW	1152
HDPC12404UGR	4000	6528	40	-	-	-	1152
HDPC12404UGRDA	4000	6528	40	DALI-2	-	-	1152
HDPC12404UGRDAEM	4000	6528	40	DALI-2	EM3H	-	1152
HDPC12404UGREM	4000	6528	40	-	EM3H	-	1152
HDPC12404UGRMWEM	4000	6528	40	-	EM3H	MW	1152
HDPC12404UGRMW	4000	6528	40	-	-	MW	1152
HDPC15604	4000	9792	60	-	-	-	1452
HDPC15604DA	4000	9792	60	DALI-2	-	-	1452
HDPC15604DAEM	4000	9792	60	DALI-2	EM3H	-	1452
HDPC15604EM	4000	9792	60	-	EM3H	-	1452
HDPC15604MWEM	4000	9792	60	-	EM3H	MW	1452
HDPC15604MW	4000	9792	60	-	-	MW	1452
HDPC15604UGR	4000	9792	60	-	-	-	1452
HDPC15604UGRDA	4000	9792	60	DALI-2	-	-	1452
HDPC15604UGRDAEM	4000	9792	60	DALI-2	EM3H	-	1452
HDPC15604UGREM	4000	9792	60	-	EM3H	-	1452
HDPC15604UGRMWEM	4000	9792	60	-	EM3H	MW	1452
HDPC15604UGRMW	4000	9792	60	-	-	MW	1452

HYDROLUX PMMA – IK08

ARTIKEL	CCT	LUMEN	WATT	DIM	NOOD	SENSOR	LENGTE mm
HDPM06204	4000	3400	20	-	-	-	552
HDPM06204DA	4000	3400	20	DALI-2	-	-	552
HDPM06204MW	4000	3400	20	-	-	MW	552
HDPM06204UGR	4000	3400	20	-	-	-	552
HDPM06204UGRDA	4000	3400	20	DALI-2	-	-	552
HDPM06204UGRMW	4000	3400	20	-	-	MW	552
HDPM12404	4000	6800	40	-	-	-	1152
HDPM12404DA	4000	6800	40	DALI-2	-	-	1152
HDPM12404DAEM	4000	6800	40	DALI-2	EM3H	-	1152
HDPM12404EM	4000	6800	40	-	EM3H	-	1152
HDPM12404MWEM	4000	6800	40	-	EM3H	MW	1152
HDPM12404MW	4000	6800	40	-	-	MW	1152
HDPM12404UGR	4000	6800	40	-	-	-	1152
HDPM12404UGRDA	4000	6800	40	DALI-2	-	-	1152
HDPM12404UGRDAEM	4000	6800	40	DALI-2	EM3H	-	1152
HDPM12404UGREM	4000	6800	40	-	EM3H	-	1152
HDPM12404UGRMWEM	4000	6800	40	-	EM3H	MW	1152
HDPM12404UGRMW	4000	6800	40	-	-	MW	1152
HDPM15604	4000	10200	60	-	-	-	1452
HDPM15604DA	4000	10200	60	DALI-2	-	-	1452
HDPM15604DAEM	4000	10200	60	DALI-2	EM3H	-	1452
HDPM15604EM	4000	10200	60	-	EM3H	-	1452
HDPM15604MWEM	4000	10200	60	-	EM3H	MW	1452
HDPM15604MW	4000	10200	60	-	-	MW	1452
HDPM15604UGR	4000	10200	60	-	-	-	1452
HDPM15604UGRDA	4000	10200	60	DALI-2	-	-	1452
HDPM15604UGRDAEM	4000	10200	60	DALI-2	EM3H	-	1452
HDPM15604UGREM	4000	10200	60	-	EM3H	-	1452
HDPM15604UGRMWEM	4000	10200	60	-	EM3H	MW	1452
HDPM15604UGRMW	4000	10200	60	-	-	MW	1452
